January 15, 2011

Using SQL Server Profiler with EF

Using SQL Server Profiler with EF

I’m a big fan of the SQL Server profiler for figuring out what the Entity Framework (EF) is really doing on the wire. If you’re unfamiliar with how to use the profiler, the easiest thing to do once you’ve got it started is File | New Trace. It will ask to which database you’d like to connection and then pop-up the Trace Properties window. If you click on the Events Selection tab, you can filter the events you see. For tracing EF, it doesn’t matter what type of events we see, but it does matter from whom they come. To see EF calls (or any ADO.NET calls) against your database, the easiest thing to do is to press the Column Filters button and set the ApplicationName to be like .NET SqlClient Data Provider”:

clip_image001

When you press the Run button, you’ll see a rolling list of calls made to that instance of SQL Server from EF. Now when you run an EF program, you’ll see exactly what SQL that EF is generating for SQL Server:

clip_image002

This is a handy technique to see whether EF batches SQL statements when you call SaveChanges (EF4 doesn’t batch) or how many round-trips lazy loading will cost you (lots — prefer the Include method).

January 7, 2011

Be Careful with Data Services Authentication + Batch Mode

Be Careful with Data Services Authentication + Batch Mode

I was doing something quite innocent the other day: I was trying to provide authentication on top of the .NET 4.0 WCF Data Services (DS) on a per method basis, e.g. let folks read all they want but stop them from writing unless they’re an authorized user. In the absence of an authorized user, I threw a DataServicesException with a 401 and the right header set to stop execution of my server-side method and communicate to the client that it should ask for a login.

In addition, on the DS client, also written in .NET 4.0, I was attempting to use batch mode to reduce the number of round trips between the client and the server.

Once I’d cleared away the other bugs in my program, it was these three things in combination that caused the trouble.

The Problem: DataServicesException + HTTP 401 + SaveChanges(Batch)

Reproducing the problem starts by turning off forms authentication in the web.config of a plain vanilla ASP.NET MVC 2 project in Visual Studio 2010, as we’re going to be building our own Basic authentication:


Next, bring in the Categories table from Northwind into a ADO.NET Entity Data Model:


The model itself doesn’t matter — we just need something to allow read-write. Now, to expose the model, add a WCF Data Service called NorthwindService” and expose the NorthwindEntities we get from the EDMX:

public class NorthwindService : DataService<NorthwindEntities> {

  public static void InitializeService(DataServiceConfiguration config) {
    config.SetEntitySetAccessRule("Categories", EntitySetRights.All);
    config.DataServiceBehavior.MaxProtocolVersion =
      DataServiceProtocolVersion.V2;
  }
  ...
}

Notice that we’re allowing complete read/write access to categories on our service, but what we really want is to let everyone read and only allow authenticated users to write. We can do that with a change interceptor:

[ChangeInterceptor("Categories")]
public void OnChangeCategory(Category category, UpdateOperations operation) {
  // Authenticate
  string[] userpw = GetCurrentUserPassword();
  if (userpw == null ||
    !userpw[0].Equals("admin", StringComparison.CurrentCultureIgnoreCase) ||
    !userpw[1].Equals("pw")) {

    HttpContext.Current.Response.
AddHeader("WWW-Authenticate", "Basic realm=\"Northwind\""); throw new DataServiceException(401, "Unauthorized");
} } // Use HTTP Basic authentication string[] GetCurrentUserPassword() { string authorization = HttpContext.Current.Request.Headers["Authorization"]; if (string.IsNullOrEmpty(authorization)) { return null; } if (!authorization.StartsWith("Basic")) { return null; } byte[] base64 = Convert.FromBase64String(authorization.Substring(6)); string[] userpw = Encoding.ASCII.GetString(base64).Split(':'); if (userpw.Length != 2) { return null; } return userpw; }

The change interceptor checks whether the client program provided a standard HTTP Basic authentication header and, if so, pulls out the admin user name/password pair. If it isn’t found, we set the WWW-Authenticate” header and throw a DataServicesException, which will turn into an HTTP error response, letting the client know I need some credentials, please.”

The code itself is very simplistic and if you want better code, I recommend Alex James’s most excellent blog series on Data Services and Authentication. However, it’s good enough to return a 401 Authorized HTTP error back to the client. If it’s the browser, it’ll prompt the user like so:


The browser isn’t a very interesting program, however, which is why I added a service reference for my new service to my plain vanilla console application and wrote this little program:

class Program {
  static void Main(string[] args) {
    var service =
new NorthwindEntities(new Uri(@"http://localhost:14738/NorthwindService.svc"));


service.Credentials = new NetworkCredential("admin", "pw");
var category = new Category() { CategoryName = "My Category" }; service.AddToCategories(category); //service.SaveChanges(); // works service.SaveChanges(SaveChangesOptions.Batch); // #fail

Console.WriteLine(category.CategoryID); } }

Here we’re setting up the credentials for when the service asks, adding a new Category and calling SaveChanges. And this is where the trouble started. Actually, this is where the trouble ended after three days of banging my head and 4 hours with the WCF Data Services team (thanks Alex, Pablo and Phani!). Anyway, we’ve got three things interacting here:

  1. The batch mode SaveChanges on the DS client which bundles your changes into a send OData round-trip for efficiency. You should use this when you can.
  2. The DataServicesException which bundles extra information about your server-side troubles into the payload of the response so that a knowledgeable client, like the .NET DS client, can pull it out for you. You should use this when you can.
  3. The HTTP authentication scheme which doesn’t fail when it doesn’t get the authentication it needs, but rather asks for the client to provide it. You should use this when you can.

Unfortunately, as of .NET 4.0 SP0, you can’t use all of these together.

What happens is that non-batch mode works just fine when our server sends back a 401 asking for login credentials, pulling the credentials out of the server reference’s Credentials property. And so does batch mode.

However, where batch mode falls down is with the extra payload data that the DataServicesExpection packs into the HTTP error resposne, which confuses it enough so that the exception isn’t handled as a request for credentials, but rather reflected back up to the client code. It’s the interaction between all three of these that causes the problem, which means that until there’s a fix in your version of .NET, you need a work-around. Luckily, you’ve got three to choose from.

Work-Around #1: Don’t Use DataServiceException

If you like, you can turn off the extra information your service endpoint is providing with the DataServiceException and just set the HTTP status, e.g.

HttpContext.Current.Response.AddHeader("WWW-Authenticate", "Basic realm=\"Northwind\"");
//throw new DataServiceException(401, "Unauthorized");
HttpContext.Current.Response.StatusCode = 401;
HttpContext.Current.Response.StatusDescription = "Unauthorized";
HttpContext.Current.Response.End();

This fix only doesn’t work with Cassini, but Cassini doesn’t work well in the face of HTTP authentication anyway, so moving to IIS7 should be one of the first things you do when facing an authentication problem.

Personally, I don’t like this work-around as it puts the onus on the service to fix a client problem and it throws away all kinds of useful information the service can provide when you’re trying to test it.

Work-Around #2: Don’t Use Batch-Mode

If you use SaveChanges(SaveChangesOptions.None)” or SaveChanges()” (None is the default), then you won’t be running into the batch-mode problem. I don’t like this answer, however, since batch-mode can significantly reduce network round-trips and therefore not using it decreases performance.

Work-Around #3: Pre-Populate the Authentication Header

Instead of doing the call an endpoint,” oops I need credentials,” here you go” dance, if you know you’re going to need credentials (which I argue is most often the case when you’re writing OData clients), why not provide the credentials when you make the call?

var service =
new NorthwindEntities(new Uri(@http://localhost/BatchModeBug/NorthwindService.svc));


service.SendingRequest += delegate(object sender, SendingRequestEventArgs e) { var userpw = "admin" + ":" + "pw"; var base64 = Convert.ToBase64String(Encoding.ASCII.GetBytes(userpw)); e.Request.Headers.Add("Authorization", "Basic " + base64); };

Notice that we’re watching for the SendingRequest event on the client-side so that we can pre-populate the HTTP Authentication header so the service endpoint doesn’t have to even ask. Not only does this work around the problem but it reduces round-trips, which is a good idea even if/when batch-mode is fixed to respond properly to HTTP 401 errors.

December 29, 2010 spout

Enabling the Tip Calculator in Your Brain

I can’t imagine anyone reading this blog needs to read this, but I can’t help myself.

When I was just a wee lad, probably the most valuable thing I learned was how to perform mathematical estimation, the importance of which and several techniques you can get by reading Jon Bentley’s The Back of the Envelope (this essay along with several others, are collected in his most excellent books Programming Pearls and More Programming Pearls, both of which are still relevant a decade later). Not only is estimation generally quicker than running a calculator, but even when you do run a calculator, it helps you figure out when you did it wrong, the latter of which has saved my bacon time and again.

For example, as much as I love the Windows Phone 7 marketplace and it’s quality and quantity of applications, the ones that puzzle me are the tip calculator” apps (several!). I don’t understand why it’s worth the trouble of pulling out your phone and punching buttons when you can know the tip instantly.

For example, let’s assume the dinner bill is $37.42. If the service was bad, that’s a 10% tip (you have to tip them something cuz the IRS assumes you will and taxes them accordingly — bastards). So, with a 10% tip, take the bill and move it right one decimal point: $3.74. Now, round up or down depending on how bad the service was, e.g. $3.50 or $4. Quick and easy.

Assuming the service was great, that’s a 20% tip, so double the bill and move it right one decimal point, making the math easier for yourself, e.g. $37.42 is close to $35, doubling is $70, so a $7 tip. Boom: 20% tip.

If you want to get fancy and provide a 15% tip for good but not great, then average the two numbers: ($4 + $7)/2 = $5.50. Zim zam zoom.

Honestly, as great as the apps are on your phone, tablet or BlueTooth headset (seriously), think about using the apps in your head first. Now only are they quicker and cheaper, but using them staves off dementia (which is a good thing!).

Oh, and if the tip is added as a mandatory minimum, then the additional tip is easy: $0.00. I don’t deal well with authority.

December 18, 2010

Windows Phone 7: Beating Expectations

Years ago, when I was on my T-Mobile Dash, I would purchase a new phone every quarter or so, just to see if something better had come along. Always, within a week or so, I returned it and went happily back to my T-Mobile Dash. Then came the iPhone, which I instantly fell in love with. I didn’t think I’d ever give it up. Then came the Samsung Focus, one of the first Windows Phone 7 phones and I haven’t turned my iPhone 4 back on since. It’s not all I’d hoped for, but it’s damn close!

Meeting Expectations

Let’s check my list and see how WP7 did:

  • A calculator, including scientific features: check.
  • A battery that lasts 24 hours: no. Unfortunately my Focus is as power hungry as any smartphone.
  • An easy, high-quality way to run the music through my car stereo: sorta. I can attach the phone to my car stereo, but it’s through the headset jack, so the quality isn’t what it should be and I need a separate attachment to charge, which causes interference on my radio. Much less than ideal.
  • Easy airplane mode: check.
  • Great auto-correct on my soft keyboard: yes! The Samsung has a soft keyboard, although other models have hard keyboards for you folks that want them (both landscape and portrait). Not only is the auto-correct generally correct, but it shows the list of words it’s gonna guess in case I want to pick one myself and, after I’m done typing, I can go back, pick a word that didn’t come out right and select a different guess or type it again myself. Brilliant!
  • Copy-paste: not yet, although I’m sure we’ll have it soon. BTW, I’m not on the WP7 team and have no special access to what is shipping or when. I just have faith in the team.
  • Full calendar support:
    • Sync’ing with Exchange and not Exchange: check.
    • Recognition of phone numbers and addresses w/ links: check.
    • Reply All to an appointment: check. In fact, there’s even an I’m running late” button. Sweet!
    • Show my appointments on the home screen: big check! Not only is my next appointment shown on the home screen, but it’s also on my lock screen along with the meeting duration and location.
    • I only have my calendar appointments in one calendar, but if I wanted to spread appointments across multiple calendars, it’ll overlay them.
  • Wireless sync’ing to my PC: check! This was a stretch goal when I wrote it, but it works like a charm.
  • Tethering: sorta. Out of the box, it doesn’t work, but apparently there’s a hack I can try. I haven’t.
  • Turn-by-turn directions: sorta. AT&T ships a turn-by-turn directions app out of the box which you can activate for $10/mo, which isn’t worth it to me compared with the less functional free app. Plus, there seems to be no integration of AT&T’s map app with the rest of my phone, e.g. clicking on a location link doesn’t bring up their app and I can’t choose a route to one of my own contacts. In fact, with the lack of copy/paste (right now), the only way to get an address into the think is to type it. Ick!

    Further, I really don’t like the built-in maps app for directions. Too much screen real estate is occupied by the directions and not enough to the map. Also, I really want to see the yellow dot and my next turn, but those are very, very difficult to get on the screen at the same time. That should just happen for me automatically.
  • Pandora playing in the background: no. Not only is Pandora missing, but 3rd party music apps don’t run in the background, which I really miss.
  • Install apps from other sources: no. There was a side-loading app out there, but it’s down now. Right now, it’s $99 for developers to side-load and no one else.
  • Let me install extra memory: check, although only for selected models (my Focus is one of them) and only if you’re willing to reset your phone. Since the Zune software doesn’t seem to do full backups, that might be a painful process, but when the WP7-Certified SD cards out, that could be up to 32GB of additional memory, which will be worth some trouble. Right now I have more good stuff I want to load onto my phone than will fit.
  • Let me replace the battery: check!
  • Great audio and ebook reading experience: not yet. I haven’t tried an audio book on it yet, but I don’t see Windows Phone 7 mentioned on the audible.com site. I do know there’s no Kindle software on the phone yet (apparently it’ll be there RSN), but until then, I don’t know what the reading experience is except for browsing the web.
  • Phone-wide search: no.
  • Full contact look-up: check, including Exchange lookup, although the search only seems to get names and not other things, like notes, which I miss. The Exchange contact lookup does include details that other phones miss, however, like their office number.
  • Good camera (and flash): almost. The camera is 5MB and the video is there and there’s a flash, but the quality could be better. My iPhone 4 spoiled me here.
  • Apps I can’t live without:
    • Evernote: no, but OneNote is way better.
    • Social networking clients: check, including deep FaceBook integration.
    • Unit and Currency Converter: check.
    • Flashlight: check, although I want an app that turns my flash on — now that’s a flashlight!
    • TripIt: no, but there’s My Trips, which shows promise, and m.tripit.com, which works well.
    • Flixster: check.
    • OpenTable: check.
    • UrbanSpoon: no.
    • Mint: no and there is no mobile version of mint.com, so I really miss this.
    • Shazam: check and it’s integrated with the Zune marketplace. Half the songs I want don’t show up when I search for them, though, so that’s not cool.
    • Skype: no.
    • Tetris: check.

Stuff I Forgot To Ask For

I believe that the universe gives you what you ask for and in this case, even if I didn’t get everything, there was even some stuff I forgot to request:

  • After have a unified inbox, I miss it now that it’s gone. Of course, I never had the unified inbox I really wanted, but I can keep hoping.
  • I didn’t know how much I’d miss DropBox and Pandora til they were gone. There is a frontend for WP7 that works with my DropBox account called BoxFiles, but it doesn’t actually let me read any of my files, so it still has some room for improvement. Also, last.fm does not have anything like the same kind of algorithm for picking songs for me that Pandora does, so I’m missing Pandora. I have come to really like Slacker for music, however.
  • I didn’t know I wanted a browser that supported HTML5, ES5 and CSS3 until I started working in that field.
  • I can’t seem to make MMS work on my phone, although other people can, so I assume it’s an account issue. I’ll keep trying.
  • Fast application startup. Some do, some don’t. I wish they all did.

Beating Expectations

Seriously, ever day is something new and cool on this phone. I continue to get blown away by features I never thought I’d want that have really changed how I use my phone:

  • The way OneNote works is game changing. I keep lots of random notes about things and to have the phone seamlessly sync with the web and my PC is wonderful. The web site needs search and the phone needs better auto-sync’ing (right now if you don’t press the Sync button sometimes, you can get sync conflicts more than you expect), but it already works so well, it’s hard to complain. Plus, you can pin favorite notes, like your grocery list, to the home screen. Beautiful!

    I am a paid Evernote user, but free OneNote is better. The PC client is 10x better for keyboard users (i.e. me) and it’s free, assuming you have Office.

  • Live Tiles really do get me in and out faster. I know the commercials are there as marketing, but I really love seeing how many unseen (not unread) emails I have and the latest picture from my roll and the latest updates from my favorite contacts and the latest weather and my next appointment and and and…

    In fact, I like Live Tiles so much that I wish the little screen to the right of the home screen used them, too. I’d like to just have a set of Live Tile screens arranged horizontally where all my installed apps live, just arranged in priority order according to my own design. Getting rid of the long list to the right of the home screen would be very appreciated.

  • Automatic uploading of pictures to SkyDrive is so cool!

  • The Back button. It works so well that browsing from apps to web content, e.g. following a link from an RSS reader or an email, feels like an extension of the app itself. I had no idea how much I liked it til I picked up an iPad and it wasn’t there.

  • It is amazing to me how well voice dialing and voice search work. That alone cuts down on half of my typing on the device.

  • The quality of the calls is 10x better than my old phone and the number of dropped calls is 10x less. There ain’t nothing wrong with AT&T. Since I work from home and have no land line, this makes a huge difference in the quality of my life.

  • The Bose Bluetooth works very well with WP7. The pairing is seamless, the call quality is high for both parties, the volume buttons are on the hardware and easy to use, the in-ear fitting is solid and comfortable with no need for an over-the-ear hook, it charges quickly and it shares the micro USB connector with my phone, so I can share the cables. And, unlike the Jawbone, the quality of the audio is good enough to enable voice dialing, so I can really do the hands free thing that Oregon and Washington require by law.

  • Trial Mode means that I can try nearly every app in the app store! If you’re an app dev, it’s your job to ship your app in trial mode and make it so compelling that I’ll beg to pay for it and WP7 encourages that, which is good for consumers. Win-win.

  • I was never an Instapaper user til I got my WP7. Now, when I find something on my phone that I don’t have to read, I can mail it to my Instapaper email address and read it later with the Text view, which looks great on my phone. Or, if I press the Read Later button in IE9, then I’ve always got plenty to read on the go on my phone. Between that and the RSS Feed support in Outlook that sync’s automatically through Exchange to my phone, I’ve always got plenty to read, which I so love.

  • It seems like a small thing, but I love being able to link multiple contacts together from Exchange, Live, FaceBook, etc., into a single contact so that my searches find the person I’m looking for, not the 5 people that my phone thinks I might mean.

  • Another small thing, but it means that I don’t miss meetings, is the snooze button on my appointments. I thank you and my boss thanks you.

Where Are We?

According to my math, I got a little more half what I asked for, but true love can’t be measured in percentages. Of the features that I’m missing, only camera quality, copy-paste and Kindle are things I actually miss from my iPhone 4, and two of those are supposed to be fixed in software RSN.

On the other hand, my Samsung Focus has giving me more than a dozen things I never thought to ask fore and really use. The full calendar support, contact linking, voice dialing (with great Bluetooth support), voice searching, the auto-correct on the keyboard, the location and phone number recognition and OneNote sync’ing make this phone a delight to use every day.

December 14, 2010

If you want something from eBay, don’t bid on it!

I’m fond of quoting my father to my sons. I have a terrible memory for these kinds of things in general, but what he says sticks with me:

  • Anything worth doing is worth doing right.” –Mike Sells
  • Don’t start a fight, but be ready to finish one.” –Mike Sells
  • Who got the goddamn jelly in the goddamn peanut butter?!” –Mike Sells

I’ve learned a ton of things from my father and continue to do so, so when I wanted to win something on eBay as a Christmas present for my girlfriend/fiancé’ (what’s it called when you’re engaged to be engaged?), I knew he had the experience, so I tapped it. And here’s what he told me:

If you really want something on eBay, don’t bid on it; that only gives your competition information on how to outbid you.

Instead, set yourself some free time when the auction is going to happen and start up two browser window at the following pages:

  1. The page where the count-down timer is shown.
  2. The page where you have already entered your top bid and are poised at the Confirm Bid button.

The idea is that people’s top bid” changes over time as the auction goes on. I know this happens to me:

Oh, this is only worth $20 to me. Well, maybe $25. OK, $40, but that’s all. Dammit I gotta have it! Where’s the button to enter the Social Security number of my first born!?”

So, instead of putting in your top bid and walking away, which lets other folks probe your top bid with their top bid and deciding later that their top bid goes toppier, wait til the last minute to put in your bid. I believe the practice is called sniping” and there are even apps that do it, although so far, I’ve found IE and a cool hand sufficient.

Of course, the most important question is this:

Dad, at what time in the countdown do I press the Confirm Bid button?”

Oh, well, I do it at 4 seconds, but my computers are slow.”

What can I say; the man’s a pro.

December 11, 2010

Fluent-Style Programming in JavaScript

Fluent-Style Programming in JavaScript

I’ve been playing around with JavaScript a great deal lately and trying to find my way. I last programmed JS seriously about 10 years ago and it’s amazing to me how much the world has changed since then. For example, the fifth edition of ECMAScript (ES5) has recently been approved for standardization and it’s already widely implemented in modern browsers, including my favorite browser, IE9.

Fluent LINQ

However, I’m a big C# fan, especially the fluent API style of LINQ methods like Where, Select, OrderBy, etc. As an example, assume the following C# class:

class Person {
  public Person() { Children = new List<Person>(); }
  public string Name { get; set; }
  public DateTime Birthday { get; set; }
  public int Age { get { return (int)((DateTime.Now - Birthday).Days / 365.25); } }
  public ICollection<Person> Children { get; private set; }
  public override string ToString() { return string.Format("{0} ({1})", Name, Age); }
}
Creating a set of them is a matter of using the C# member initialization syntax:
var chris = new Person() {
  Name = "Chris",
  Birthday = new DateTime(1969, 6, 2),
  Children = {
    new Person() {
      Name = "John",
      Birthday = new DateTime(1994, 5, 5),
    },
    new Person() {
      Name = "Tom",
      Birthday = new DateTime(1995, 8, 30),
    },
  },
};
Without even realizing it, I used the word set” to describe how I think of this collection of people. That’s how the LINQ methods encourage me to think and I like it — I’m working on sets of things, whether I’m filtering them, projecting them, ordering them, aggregating them in some way, etc. For example, here’s how I would print all of the items in my set:
var people = new Person[] { chris }.Union(chris.Children);
Console.WriteLine("People: " +
  people.Aggregate("", (s, p) => s + (s.Length == 0 ? "" : ", ") + p.ToString()));
Console.WriteLine("Teens: " +
  people.Where(p => p.Age > 12 && p.Age < 20).
    Aggregate("", (s, p) => s + (s.Length == 0 ? "" : ", ") + p.ToString()));
Here I’m using the Union method to combine all three elements into a new set, the Where method to filter one set to produce another and the Aggregate method to produce a single string. The output should be unsurprising:
People: Chris (41), John (16), Tom (15)
Teens: John (16), Tom (15)

Fluent JavaScript

LINQ is lousy with such set-oriented functions, e.g. Select, OrderBy, Take, Skip, First, Single, etc. and I use them a ton in my code (and my scripts). As it turns out, JS has these methods, too, both provided by popular JS toolkits like jQuery and in the language itself. Specifically, ES5 has a number of lovely methods for fluent programming. For example, given the same class” in JS:
// Person constructor
function Person(args) {
  if (args.name) { this.name = args.name; }
  if (args.birthday) { this.birthday = args.birthday; }
  if (args.children) { this.children = args.children; }
}

// Person properties and methods
Person.prototype = Object.create(null, {
  name: { value: "", writable: true },
  birthday: { value: new Date(), writable: true },
  age: { get: function () { return Math.floor((new Date() - this.birthday) / 31557600000); } },
  children: { value: [], writable: true },
  toString: { value: function () { return this.name + " (" + this.age + ")"; } }
});

I can do several LINQ-style things on it:

var s = "";
var tom = new Person({ name: "tom", birthday: new Date(1995, 7, 30) });
var john = new Person({ name: "john", birthday: new Date(1994, 4, 5) });
var chris = new Person({ name: "chris", birthday: new Date(1969, 5, 2), children: [tom, john] });
var people = [tom, john, chris];

// select
s += "<h1>people</h1>" + people.map(function (p) { return p; }).join(", ");

// where
s += "<h1>teenagers</h1>" + people.filter(function (p) { return p.age > 12 && p.age < 20 }).join(", ");

// any
s += "<h1>any person over the hill?</h1>" + people.some(function (p) { return p.age > 40; });

// aggregate
s += "<h1>totalAge</h1>" + people.reduce(function (totalAge, p) { return totalAge += p.age; }, 0);

// take
s += "<h1>take 2</h1>" + people.slice(0, 2).join(", ");

// skip
s += "<h1>skip 2</h1>" + people.slice(2).join(", ");

// sort
s += "<h1>sorted by name</h1>" + people.slice(0).sort(
  function (lhs, rhs) { return lhs.name.localeCompare(rhs.name); }).join(", ");

// dump
document.getElementById("output").innerHTML = s;

Notice that several things are similar between JS and C# LINQ-style:

  • The array and object initialization syntax looks very similar so long as I follow the JS convention of passing in an anonymous object as a set of constructor parameters.
  • The JS Date type is like the .NET DateTime type except that months are zero-based instead of one-based (weird).
  • When a Person object is added” to a string, JS is smart enough to automatically call the toString method.
  • The JS map function lets you project from one set to another like LINQ Select.
  • The JS filter function lets you filter a set like LINQ Where.
  • The JS some function lets you check if anything in a set matches a predicate like LINQ Any.
  • The JS reduce function lets you accumulate results from a set like the LINQ Aggregate.
  • The JS slice function is a multi-purpose array manipulation function that we’ve used here like LINQ Take and Skip.
  • The JS slice function also produces a copy of the array, which is handy when handing off to the JS sort, which acts on the array in-place.

The output looks as you’d expect:


We’re not all there, however. For example, the semantics of the LINQ First method are to stop looking once a match is found. Those semantics are not available in the JS filter method, which checks every element, or the JS some method, which stops once the first matching element is found, but returns a Boolean, not the matching element. Likewise, the semantics for Union and Single are also not available as well as several others that I haven’t tracked down. In fact, there are several JS toolkits available on the internet to provide the entire set of LINQ methods for JS programmers, but I don’t want to duplicate my C# environment, just the set-like thinking that I consider language-agnostic.

So, in the spirit of JS, I added methods to the build in types, like the Array type where all of the set-based intrinsics are available, to add the missing functionality:

Object.defineProperty(Array.prototype, "union", { value: function (rhs) {
  var rg = this.slice(0);
  rhs.forEach(function (v) { rg.unshift(v); })
  return rg;
}});

Object.defineProperty(Array.prototype, "first", { value: function (callback) {
  for (var i = 0, length = this.length; i < length; ++i) {
    var value = this[i];
    if (callback(value)) { return value; }
  }
  return null;
}});

Object.defineProperty(Array.prototype, "single", { value: function (callback) {
  var result = null;
  this.forEach(function (v) {
    if (callback(v)) {
      if (result != null) { throw "more than one result"; }
      result = v;
    }
  });
  return result;
}});

These aren’t perfectly inline with all of the semantics of the built-in methods, but they give you a flavor of how you can extend the prototype, which ends up feeling like adding extension methods in C#.

The reason to add methods to the Array prototype is that it makes it easier to continue to chain calls together in the fluent style that started all this experimentation, e.g.

// union
s += "<h1>chris's family</h1>" +
[chris].union(chris.children).map(function (p) { return p; }).join(", ");

Where Are We?

If you’re a JS programmer, it may be that you appreciate using it like a scripting language and so none of this set-based” nonsense is important to you. That’s OK. JS is for everyone.

If you’re a C# programmer, you might dismiss JS as a toy” language and turn your nose up at it. This would be a mistake. JS has a combination of ease-of-use for the non-programmer-programmer and raw power for the programmer-programmer that makes it worth taking seriously. Plus, with it’s popularity on the web, it’s hard to ignore.

If you’re a functional programmer, you look at all this set-based programming and say, Duh. What took you so long?”

Me, I’m just happy I can program the way I like to in my new home on the web. : )

December 11, 2010 tools

Using LINQPad to Run My Life: Budgeting

Using LINQPad to Run My Life: Budgeting

I use LINQPad all the time for a bunch of stuff, but most recently and most relevant, I’ve been using it for a personal chore that isn’t developer-related: I’ve been using it to do budgeting.

What is LINQPad?

LINQPad is an interactive execution environment for LINQ queries, statements or programs. The typical usage model is that you point LINQPad at a SQL database or an OData endpoint via a dialog box and then start writing queries against the tables/collections exposed by that connection, e.g.

clip_image002

Here, you can see that I’ve added a connection on the left to the Northwind database, typed a query into the text box (I paid the $25 for the auto-completion module), executed the query and got the table of results below. If I want to operator over multiple results, including dumping them for inspection, I can do so by switch from C# Expression to C# Statements:

clip_image004

Notice the use of Dump” to see results along the way. If I want to, I can switch to C# Program, which gives me a main and allows me to create my own types and methods, all of which can be executed dynamically.

To save queries, notice the My Queries” tab in the lower left. I use this for things I run periodically, like the ads on my web site that are going to expire, some data cleanup I want to get back to and, the subject of today: budgeting.

Budgeting with Mint.com and LINQPad

For the uninitiated, mint.com is a free online personal financial management site. At its core, it uses financial account, loan and asset information that lets it log into various financial sites and grab my data for me, e.g. 1sttech.com, usbank.com, wcb.com, etc. It uses this to let me categorize transactions so that it can do budgeting for me. However, it doesn’t give me the control I want, so I write programs against this unified transaction information. Essentially, I re-categorize each transaction to my own set using a map I maintain in an Excel file, then compare the amount I spend each month against what my budget amount is, maintained in another sheet in that same Excel file. Because mint.com doesn’t provide a programmatic API (OData would be a godsend!), I pull down my transaction history as a CSV file that the web site provides for me, which I then translate to an Excel file.

Once I have these three Excel sheets, the translation history, the category map and the category budget amounts, I bring these pieces of data into my LINQPad script:

void Main() {
    var mintExcel = ExcelProvider.Create(@"D:\data\finances\2010-08-25 mint transactions.xlsx");
    var minDate = new DateTime(2010, 8, 1);
    var txs = mintExcel.GetSheet<Tx>().Where(t=>t.Date>=minDate);
    var debits = txs.Where(tx => tx.Type == "debit");

    var classExcel = ExcelProvider.Create(@"d:\data\finances\2010-08-03 mint category map.xlsx");
    var map = classExcel.GetSheet<CategoryClass>().ToList();
    var classBudget = classExcel.GetSheet<ClassBudget>().ToList();
    var unclassified = new ClassBudget() { Class = "UNCLASSIFIED" };
    classBudget.Add(unclassified);
    var classifiedDebits = debits.
      Select(d => new { d.Date, d.Description, Amount = d.Amount, d.Category, Class = GetClass(map, d) }).
      Where(d => d.Class != null);

    // TODO: break this down by month
    // TODO: sum this by ytd
    var classifiedTotals =
        from d in classifiedDebits
        group d by d.Class into g
        let b = classBudget.FirstOrDefault(b=>b.Class == g.Key) ?? unclassified
        let total = g.Sum(d=>d.Amount)
        select new {
            Class = b.Class,
            BudgetAmount = b.Amount,
            ActualAmount = total,
            AmountLeft = b.Amount - total,
            TxCount = g.Count(),
            Transactions = from tx in g.OrderBy(tx=>tx.Date)
                select new { Date = tx.Date.ToString("M/d/yy"), tx.Description, tx.Category, tx.Amount }
        };
    classifiedTotals.OrderBy(d=>d.Class).Dump(2);
    //classifiedTotals.OrderBy(d=>d.Class).Dump();
}

static string GetClass(List<CategoryClass> map, Tx tx) {
  CategoryClass cc = map.FirstOrDefault(m => m.Category == tx.Category);
  if( cc != null ) { return cc.Class; }
  tx.Category.Dump("UNCLASSIFIED MINT CATEGORY");
  return null;
}

[ExcelSheet(Name = "transactions(1)")]
public class Tx {
    [ExcelColumn()] public DateTime Date { get; set; }
    [ExcelColumn()] public string Description { get; set; }
    [ExcelColumn()] public decimal Amount { get; set; }
    [ExcelColumn(Name = "Transaction Type")] public string Type { get; set; }
    [ExcelColumn()] public string Category { get; set; }
    [ExcelColumn(Name = "Account Name")] public string AccountName { get; set; }
}

[ExcelSheet(Name = "Sheet1")]
public class CategoryClass {
    [ExcelColumn()] public string Category { get; set; }
    [ExcelColumn(Name="Classification")] public string Class { get; set; }
}

[ExcelSheet(Name = "Sheet2")]
public class ClassBudget {
    [ExcelColumn(Name="Classification")] public string Class { get; set; }
    [ExcelColumn()] public decimal Amount { get; set; }
    public int Transactions { get; set; }
}

There are some interesting things to notice about this script:

  • I needed to make it a full-fledged program so that I could define the shape of my data in Excel. LINQPad has no native support for Excel data, so I had modify an Excel LINQ provider I found on the interwebtubes. The types are needed to map the Excel columns to C# types so that I can query against them.
  • This script isn’t pretty; it’s been built up over time and it works. I’ve been using it for a month and this month my task is to split it work across multiple months.
  • I’ve built up error output over time to make sure I’m not dropping data in my queries. I spent an hour a coupla weeks ago tracking down 3 transactions.
  • I’m doing slow look-ups cuz at the time I wrote this script, I wasn’t sure how to write joins in LINQ. It’s more than fast enough for my needs, so I’ve only dug into LINQ for accuracy, not efficiency.

LINQPad Output

By default, the output from my budgeting program looks like this (w/ my personal financial details blacked out):

clip_image006

Some things to notice:

  • The output is spit into a table w/o me having to do anything except dump the data.
  • The number columns have an automatic bar graph glyph on them that shows proportions when clicked.
  • The number columns are automatically totally.
  • The Transactions column is turned off because I said Dump(2)”, which only dumps to the 2nd level. By default it would drill down further, e.g.

clip_image008

Bringing in Excel

To bring my Excel data into LINQPad, which supports LINQ to SQL, EF and OData natively but not Excel, I have to right-click on the design surface, choose query properties and tell it about where the source code and namespace is that defines the Excel LINQ Query Provider:



Impressions

The thing that makes this app really work for me is the REPL nature. It’s very immediate and I can see where my money is going with very little ceremony. It’s really the intelligence of the Dump command that keeps me from moving this app to WPF. Dump gives me the view I need to understand where my money goes and it gives me the programming surface to slice/dice the data the way I want to. I have no control out of the box in WPF that’s even close to as useful.

However, Even though I could extend LINQPad myself, there is no integrated support for Excel or CSV files. Further, for some stupid reason, I have to load the files into a running instance of Excel for them to load in LINQPad, which pisses me off because the error messages are ridiculous. Also, there is no intrinsic support for multiple data sources; instead I need to build that myself.

Further, I had one case where I couldn’t figure out an error (it was that I forgot to load the data into Excel) and had to have a real debugger, which LINQPad didn’t have. The good news was that I was able to copy/paste my code into a console application and debug it, but the bad news was that I really missed the Dump command when I was running inside Visual Studio.

Where Are We?

I really love LINQPad. In fact, I find myself wanting the same functionality for other uses, e.g. SQL (real SQL), JavaScript and as a shell. It’s the interactive data access that makes it for me — munge some data, look at it, repeat. It doesn’t quite do everything I want, though — where’s the full-featured, all-data, Swiss army knife for data?

October 29, 2010

Management vs. Motivation

If you want to build a ship, don’t drum up people to gather wood, divide the work, and give them orders. Instead, teach them to yearn for the vast and endless sea.”

Antoine De Saint-Exupery, author of The Little Prince”


← Newer Entries Older Entries →
